1330AE Micro
Micro Scissor design with true slide-out deck and low floor loading (Uniform Pressure: 229 lbs., Max. Localized Pressure: 112 lbs.)
Fits on most elevators and into tight work areas
No Hydraulic Oil
Product Specs
Standard Features
Work Area
Roll-Out Deck Extension with Incremental Locking Positions
Full Height Swing Gate
Lanyard Attachments
110v Power to Platform
Performance
All-Electric Drive, Lift and Steer
Fully Proportional Drive and Lift Controls
Up To 25% Gradeability
Power
24v 85Ah AGM Battery Pack (Maintenance-Free)
Battery Charge Indicator
Single 110v Receptacle at Chassis for Common Plug Connection for Battery Charger and Power to Platform
Serviceability
Lubrication-Free Scissor Bearings
Easy Maintenance Access to Mechanical and Electrical Components
Logically Grouped Components and Numbered Wiring for Easy Reference
Safety
Lift Control Orientation Designed to Mitigate Overhead Entrapment
Dedicated Compartment Protects Electrical and Hydraulic Components
Emergency Shut-Off at Platform and Lower Controls
Non-Skid Metal Deck Construction
Descent Alarm
Drive Speed Interlock
Scissor Maintenance Lock
Multi-Axis Tilt Sensor
Multiple Disc Brakes
Automatic Parking Brake
Other Features
Removable Upper Controls
Voltage-Compensating Fully Automatic Battery Charger
Hour Meter
Machine Tie Downs
Non-Marking Tires
All Motion Alarm
Fork Lift Pockets
Flashing Beacon (Continuous)
Highlights
13 ft. (3.9 m) Platform Height and 19 ft. (5.9 m) Working Height
Fits on Most Elevators with Shortest Overall Length and Low GVW (Gross Vehicle Weight)
24 in. (61 cm) Roll-Out Deck Extension with Incremental Lock Positions
All-Electric Drive, Lift and Steer
2-Person Platform (Indoors)/1-Person Platform (Outdoors) with 500 lb. (227 kg) Capacity
Fully Proportional Lift and Drive Controls
No Hydraulic Oil
Optimal Battery Duty Cycle and Energy Efficiency
Options
900W Inverter
Tool Tray
Pipe Rack
Proactive Platform Safety System® (PPSS)
Second Year Extended Warranty Cold Weather Package Anti-Fatigue Mat Upper Control Box Supplementary Guard
