4046SEAC Compact


MEC’s full line of slab scissor lifts features the industry principal 40ft platform height compact scissor
AC Electric Drive

Exceptional duty cycle with standard maintenance free batteries and higher residual value

Full-Featured Design

High spec standard features include power-to-platform, on-board diagnostic and more

Extended Duty Cycle

High energy efficiency lift and drive lasts through the day for extended productivity

Product Specs


39 ft.
Platform Height
47 in.
Machine Width
98 in.
Machine Length
750 lbs.
Platform Capacity
7,140 lbs.
Machine Weight

Standard Features

Work Area
Roll-Out Deck Extension with Incremental Locking Positions
Full Height Swing Gate
Lanyard Attachments (4)

Performance
AC Electric Drive
Fully Proportional Drive and Lift Controls

Power
24v 300Ah AGM Batteries
Battery Charge Indicator

Serviceability
Lubrication-Free Scissor Bearings
Easy Maintenance Access to Mechanical and Electrical Components in a Slide-Out Tray
Logically Grouped Components and Numbered Wiring for Easy Reference

Safety
Dedicated Compartment Protects Electrical and Hydraulic Components
Emergency Shut-Off at Platform and Lower Controls
Non-Skid Metal Deck Construction
Descent Alarm
Drive Speed Interlock
Multi-Axis Tilt Sensor
Scissor Maintenance Lock
Multiple Disc Brakes

Other Features
Leak Containment System® (LCS) Patent Number 11,112,060                    Sheet Material Tray                                                                                          Removable Upper Controls
Voltage-Compensating Fully Automatic Battery Charger
Fold-Down Guardrails
Hour Meter
Machine Tie Downs
Non-Marking Tires
All Motion Alarm
Fork Lift Pockets

4046SEAC_600_px_wide_3-2024

Highlights

Indoors: 38.7 ft. (11.8 m) Platform Height and 44.7 ft. (13.8 m) Working Height

Outdoors: 30 ft. (9.2 m) Platform Height and 36 ft. (11.2 m) Working Height

AC Electric Drive Extended Duty Cycles and Faster Drive Speeds

Compact Maneuverability from Front Wheel Drive and Steer with Zero Inside Turn Radius

Fully Proportional Lift and Drive Controls

Standard Swing Gate

Easy Serviceability with Swing Out Batter and Power Module Trays

Options

900W Inverter
Tool Tray
Pipe Rack
Second Year Extended Warranty                                                                              Cold Weather Package

Want a PDF of this brochure?

DOWNLOAD BROCHURE

Featured Options

Integrated Leak Containment System® (LCS) Patent Number 11,112,060
Contain leaks and protect flooring while not interfering with safe machine operation
900W Inverter
On board AC power at the platform for power tools and lithium power pack charging while avoiding the risks and limitations of overhanging power cords
Pipe Rack
Factory designed and authorized device for safe pipe handling that keeps the platform clear and unobstructed

Operator's Manual
Download PDF
Service & Parts Manual
Download PDF
Schematic Diagrams
Download PDF
Familiarization
Download PDF
